Schneider SM62DMHTS1C50A0000 SM6 Connected DM1-A line A/K 24 VDC Disconnector Switch w Pressure Switch
New product
|
range of product |
SM6 |
|
technology type |
Air insulated switchgear |
|
device short name |
DM1A hat/toroid |
|
product or component type |
Cubicle |
|
Internal arc protection |
16 kA 1 s |
|
Internal arc classification |
A-FL bottom exhaust gas |
|
Rated frequency (fr) |
50/60 Hz |
|
Rated voltage (Ur) |
36 kV |
|
Rated lightning impulse withstand voltage (Up) |
170 kV peak |
|
Rated short-duration power-frequency withstand voltage (Ud) |
70 kV rms 50 Hz for 1 min |
|
Rated continuous current (Ir) |
630 A |
|
Inrush current |
20000 A 4250 Hz C2 back to back capacitor bank |
|
Rated short-time withstand current (Ik) |
16 kA rms 1 s |
|
standards |
IEC 62271-200 |
